• IP Video Input: 8-ch (up to 40-ch), each up to 6 MP Resolution
• Analog Video Input: 32-ch BNC Interface (1.0 VP-P, 75 Ω), Supporting Coaxitron Connection
• Video Live: 5MP
• Video Recording: 1080P
• Video Input Types: HDTVI/AHD/CVI/CVBS/IP
• VGA Output: 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
• HDMI Output: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 ×
  1024/60Hz, 1280 × 720/60Hz
• Audio Input: 1-ch, RCA (2.0 Vp-p, 1 KΩ), 32-ch via coaxial cable
• Audio Output: 1-ch, RCA (Linear, 1 KΩ)

• Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Frame Rate: Main Stream: When 1080p Lite mode not enabled: Up To 3K lite@12fps;4 MP
  lite@15fps/1080pLite@20fps;720p/WD1/4CIF/VGA/CIF@20fps, When 1080p Lite mode enabled: Up To 3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p
  lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N), Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)

• Video Bitrate: 32 Kbps to 10 Mbps
• Stream Type: Video, Video & Audio
• Audio Bitrate: 64 Kbps

• Network Interface: 1x RJ45 10/100/1000 Mbps self-adaptive Ethernet interface
• Total Bandwidth: 256Mbps
• Remote Connection: 128

• HDD Type: 2x SATA
• Capacity: Up to 12TB Capacity for Each Disk
• USB: Front panel: 1× USB 2.0, Rear panel: 2× USB 3.0

• Operating Temperature: -10 °C to 55 °C (14 °F to +131 °F)
• Operating Humidity: 10% to 90%
• Power Supply: 12 VDC, 5 A
• Power Consumption: ≤ 60 W
• Dimensions (W × D × H): 384 x 313 x 52mm
• Weight: ≤ 2.1 kg

Warranty: 1 Year With Warranty Of The Authorized Agent
